Stainless Steel A2 and A4: Differences and Characteristics

When choosing screws, nuts, washers and other stainless steel fasteners, the A2 and A4 designations are among the most common. However, they do not simply indicate two materials that are “better” or “worse”, but two families of stainless steels used in fasteners with different characteristics, especially in terms of corrosion resistance.

In practical terms, the main difference is this: A2 stainless steel is suitable for many standard applications, both indoors and outdoors where the environment is not particularly aggressive; A4 stainless steel, on the other hand, offers better performance in more severe environments, especially where salt air, frequent washing, chlorinated water or conditions similar to the marine sector are present.

The correct choice, however, does not depend only on the designation. The operating environment, strength class, product standard and compatibility with the other materials in the assembly must also be considered.

What stainless steel means

Steel is an alloy based on iron and carbon, to which other elements can be added to obtain specific properties.

Stainless steel is the term used when the alloy contains a sufficient amount of chromium, normally at least 10.5 percent. Chromium allows a thin passive layer to form on the surface, protecting the material from corrosion in many operating conditions.

This does not mean, however, that stainless steel is immune to damage. Stainless steel can still become stained or suffer localized corrosion in the presence of chlorides, stagnant conditions, surface contamination, crevices or conditions that prevent the passive film from being maintained or correctly restored.

A2 and A4 in stainless steel fasteners

In the language of screws and fasteners, A2 and A4 are designations used for fastening elements made of austenitic stainless steel. In practical terms, A2 has corrosion-resistance characteristics generally associated with steels in the AISI 304 family, while A4 is commonly associated with the AISI 316 family. However, these designations are not perfectly equivalent, because they belong to different classification systems.

For fasteners, the product standard, the designation declared by the manufacturer, any marking required by the standard and the information provided on the packaging or in the technical documentation are always what matter.

A2 stainless steel is the most common solution for general applications: machinery, plants, light metalwork, technical furniture, indoor environments and ordinary outdoor applications. It is suitable when good corrosion behaviour is required, but there is no significant exposure to salt air, chlorinated water or particularly aggressive substances.

A4 stainless steel is more suitable when the working environment is more severe. It may be preferable in marine or saline atmospheres, in systems subject to frequent washing and, after checking the actual operating conditions, in some contexts exposed to salt or treated water. For this reason, it is often described, in simplified terms, as “marine-grade stainless steel”. However, the absolute suitability of the material cannot be established solely from the A4 designation.

AISI 304 and AISI 316: choose carefully

The designations AISI 304 and AISI 316 identify widely used families of stainless steels. The best-known difference concerns the presence of molybdenum in steels of the 316 family, an element that improves corrosion resistance in environments containing chlorides. This is why A4 stainless steel is used in many more exposed or aggressive applications.

In industrial fastening, however, reading AISI 304 or AISI 316 is not enough to choose a screw or bolt correctly.

It is necessary to verify that the product is actually suitable as a fastening element, that it complies with the applicable standards and that it carries the correct class.

A stainless steel screw, for example, may be designated A2-70 or A4-80: the first part identifies the steel group, while the number corresponds to one tenth of the minimum tensile strength expressed in MPa, respectively 700 and 800 MPa, according to the applicable standard.

Stainless steel screws and bolts: when to choose A2 or A4

A2 stainless steel screws and bolts are suitable when the fastening works in non-extreme conditions. They offer a good balance between performance, availability and cost, and are suitable for many industrial assemblies, machines, light structures and outdoor applications.

A2 becomes less advisable when the component is continuously or repeatedly exposed to salt air, chlorinated water, aggressive detergents, stagnant conditions or particularly corrosive industrial atmospheres. In these cases, A4 stainless steel should be considered or, for even more critical applications, specific solutions defined according to the project.

A4 does in fact provide better behaviour in the presence of chlorides, but it should not be considered a universal solution. The service life of the fastening depends on temperature, stagnant conditions, surface cleanliness, galvanic coupling, part geometry and maintenance.

Galvanic corrosion: standards and certifications

Another aspect that should not be overlooked is galvanic corrosion. When different metals are coupled in the presence of humidity or other electrolytes, a corrosive phenomenon can occur as a result of the combination of materials, environment, relative surface area of the components and electrical continuity.

For this reason, when a stainless steel screw is mounted on another metal, the assessment must always concern the entire assembly.

To choose stainless steel fasteners correctly, it is necessary to check the applicable dimensional and performance standard, the material designation, the strength class and, when required by the project or specifications, the relevant conformity and traceability documentation. This applies to screws, bolts, nuts, threaded rods, washers, threaded inserts, pins, retaining rings and other fastening items.

Conclusion

The difference between A2 and A4 stainless steel is mainly functional. A2 is suitable for many general applications and provides good corrosion resistance in ordinary environments. A4, thanks to its better behaviour in the presence of chlorides, is more suitable for marine, saline or aggressive environments.

For the correct choice, however, it is necessary to look beyond the designation: operating environment, mechanical class, applicable standard, any conformity requirements and compatibility of the entire assembly are the factors that determine the real service life of the fastening.
